The product is no longer sold, development has been ended, and is no longer getting updates from support, and all effort from support is best effort.
| Network standards | IEEE802.3、 IEEE802.3u、IEEE802.3x、 IEEE802.3ab |
| LED Indicator | 1 * Power，5 * Link/Act |
| Interfaces | 5*10/100/1000 Base-T Ethernet ports (Auto MDI/MDIX) |
| Transmission media | Recommended: CAT5/5e UTP or better |
| Dimension | 100.0mmx64.0mmx23.0mm |
| Material | Metal |
| Level of protection | ESD: Air discharge: ±8kV Contact discharge: ±6kV |
| Forwarding mode | Store-and-forward |
| Switch capacity | 10Gbps |
| Packet forwarding rate | 7.44Mpps |
| Buffer | 1Mb |
| MAC address table | 2K |
| Jumbo frame | 15K |
| Power | Input: 100-240V AC 50/60Hz Output: 5.0V 0.6A ( External Power Adapter ) |
| Power consumption | Max:<2.5W |
| Mounting | Desktop mounting: support Wall mounting: support Rack mounting:non-support |
| Environment | Operating temperature: 0°C - 45℃ Storage temperature: -40°C - 70°C Operating humidity: (10% - 90%) RH, non-condensing Storage humidity: (5% - 90%) RH, non-condensing |
| Certification | CE, FCC, RoHS |
| Protocols | CDMA/CD |
| MAC address learning | Auto-Learning and Auto-Aging |
| Funtions | plug-and-play |
