The product is no longer sold, development has been ended, and is no longer getting updates from support, and all effort from support is best effort.
| Interfaces | 1 * 10/100 Mbps RJ45 |
| Antenna Type | Internal antenna |
| Button | 1 * WPS/Reset，1 * Pair |
| LED Indicator | 1 * WPS，1 * Wireless，1 * Power，1 * PLC，1 * LAN |
| Power Input | AC100-240V 50/60Hz |
| Power Consumption | 4W(Maximum) |
| Dimension | 94mm*60mm*48mm(L x W x H) |
| Wireless Standard | HomeplugAV IEEE 802.3, IEEE 802.3u, IEEE 802.3ab IEEE802.11b/g/n |
| Frequency | Powerline: 2-28MHz Wireless: 2.4GHz |
| Data Rate | Poweline: 200Mbps Wireless: 2.4GHz Up to 300Mbps |
| Certification | CE, FCC、RoHS |
| Plug Type | US、EU、UK |
| Package Contents | 1 * Powerline Ethernet Adapter 1 * Quick Installation Guide 1 * Ethernet cable |
| Environment | Operating Temperature: 0°C ~ 40°C(32°F ~ 104°F) Storage Temperature: -40°F ~ 158°F (-40°C ~ 70°C ) Operating Humidity: 10% ~ 90% RH non-condensing Storage Humidity: 5% ~ 90%RH non-condensing |
| Related Products | PH3，PH5，PH6，PH10 |
