O8 1-pack 5GHz 23dBi 11ac Outdoor CPE

5GHz 23dBi 11ac Outdoor CPE

O8 5GHz 23dBi 11ac Outdoor CPE is designed to PtP and PtMP solutions for private ISP wireless connectivity, CCTV surveillance and data transmission. It features with 23dBi directional vertical polarization antenna to provide an efficient way to pick up and maintain a stable long-distance connectivity up to 20km. Adopt of auto-bridging technology, two CPE can connect to each other automatically to make it easy to setup.
Datasheet
You can click here to export the current parameters (.docx)
ModelO8
Dimension391.5*280*223mm
DeploymentPole Mount
Application ScenariosPtP and PtMP wireless connection for Privated ISP access or CCTV Surveillance
Frequency Range5GHz
Compliant StandardsIEEE 802.11a/n/ac
Private TDMA ProtocolTD-MAX
Maximum Wireless Rate433Mbps
Interfaces1*10/100Mbps Ethernet Port
Antenna PolarizationVertical Polarization
Antennas Gain23dBi
Antenna BeamwidthVertical: 10° Elevation: 10°
GND/
Reset Button1
Power Consumption5.5W
Waterproof LevelIP65
LED IndicatorPoE/LAN,LED1,LED2,LED3
Power Method12V1A Passive PoE
Lightning Protection6000V
Passive PoEPassive power over ethenet via PoE/LAN(✚4,5pins,-7,8pins )
Voltage range: 9-35V DC
Reception Sensitivity11a 6Mbps -95dBm±1.5dBm
11n MCS7 HT20 -72dBm±1.5dBm
11ac MCS9 HT80 -64dBm±1.5dBm
TDMASupport
Operating modeAP/Station/WISP/P2MP/WDS Repeater/Router
Enable/Disable Wireless RadioSupport
SSID HiddenSupport
Wireless Client isolationSupport
SSID IsolationSupport
Channel Bandwidth20/40/80MHz
Channel ShiftSupport
Wireless Access ControlSupport
Weak Signal Client LimitationSupport
Transmission PowerAdjustable power by 1dBm
WMM CapableSupport
APSD CapableSupport
Wireless Security64/128 WEP,WPA-PSK,WPA2-PSK,WPA
Transparent BridgeSupport
VLAN Tagging for SSIDSupport
DHCP ServerSupport
VPN Pass-ThroughPPTP,L2TP
Remote Web accessSupport
Schedule RebootSupport
Page TimeoutSupport
Ping WatchdogSupport
Dyndnsnoip, dyndns.org
Network DiagnosesPing, Traceroute, Signal Scan
Time and Date SettingSupport
Firmware upgradeSupport
Backup/Restore ConfigurationSupport
Username ManagermentSupport
System LogsSupport
Managed By ControllerPC Software -- CPE Assistant
Package Contents1*5GHz 23dBi 11ac Outdoor CPE O8
1*Power Adapter
1*PoE Injector
1*Quick Installation Guide
Operation Temperature-30℃ ~ 60℃
Storage Temperature-40℃ ~ 70℃
Operating Humidity10%~90% non-condensing
Storage Humidity10%~90% non-condensing
Default login IP192.168.2.1
Default Login Usernameadmin
Default Login Passwordadmin
CertificationFCC/CE/RoHS
