TEG1118P-16-250W 16GE+2SFP Ethernet Switch With 16-Port PoESpecification

Gallery

Hardware

Network standards

IEEE 802.3/IEEE 802.3u/IEEE 802.3ab/IEEE 802.3x/ IEEE 802.3af/IEEE 802.3at

LED Indicator

16 * Link/Act LEDs
2 * SFP LED
1 * PoE-MAX LED
1 * Power LED

Interfaces

16*10/100/1000 Base-T ports(Data/Power)

Transmission media

Recommended: CAT5/5e UTP or better

Fan quantity

Dimension

440*178.8*44mm

Level of protection

Lightning protection for ports: 6kV
Lightning protection for power: 6kV
ESD:
Air discharge: ±10kV
Contact discharge: ±8kV

Forwarding mode

Store-and-forward

Switch capacity

36bps

Packet forwarding rate

26.8Mpps

Buffer

MAC address table

Jumbo frame

N/A

PoE budget

Single port: AF: 15.4W, AT: 30W
Whole device: 230W

Power consumption

Input voltage

100-240V AC 50/60Hz

Mounting

Desktop mounting: support
Wall mounting: support
Rack mounting : support

Environment

Operating Temperature: 0℃~45℃
Storage Temperature: -40℃~70℃
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing

Certification

FCC、CE、RoHS
