CP3 V2.2 Security Pan/Tilt Camera 1080PSpecification

Gallery

Camera

Image Sensor

1/3 Progressive Scan CMOS sensor

Day and Night

ICR type

Bracket Angle Adjustment

Lens

Focal Length

4mm

Aperture

F2.2

FOV

Horizontal : 79.4°, Vertical : 48°, Diagonal : 87°

Illuminator

Supplementary Light

4 IR Lights

Supplementary Light Distance

Up to 10 m/32 ft (depending on environment)

IR Wavelength

850nm

Night Vision Mode

Black & White Mode

Video

Video Encoding Format

H.264

Main Stream Resolution

1920 × 1080, 1280 × 720

Sub Stream Resolution

640 x 360

Frame Rate

1-15fps,Default 15fps

Bit Rate

256kbps -- 8192kbps

Bit Rate Control

VBR

Audio

Audio Encoding Format

G.711A

Audio Sampling Rate

8 kHz

Audio Communication

Two-way Audio


Image Enhancement

DWDR, 3D DNR

Privacy Mask

Network

Ethernet Port

ONVIF

Support

Protocols

TCP/IP, UDP, ICMP, HTTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, ARP

Web Browser

Pan&Tilt

Pan Movement Range

0°--355°

Tilt Movement Range

-65°--90°

Preset

Patrol

Panoramic Patrol, Preset Patrol

Wi-Fi

Antenna

Internal antenna

Wireless Standard

IEEE 802.11 b/g/n

Transmission Rate

Up to 144Mbps

Channel Width

20 MHz

Modulation

DSSS/OFDM

Frequency Band

2.4GHz: 2412MHz-2472MHz(CH1-CH13)

Transmit Power

2.4GHz: <0.062W(EIRP)

Security

64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK

Alarm

Smart Detection

Motion Detection, Human Detection

Smart Linkage

Sound&light Alert, Human Tracking

DIY Audio

3 Customized Audios

Interface

Audio Input

Built-in MIC

Audio Output

Built-in Speaker

Storage

Built-in Micro SD Card Slot, Up to 256 GB

Reset Button

Support

LED Indicator

Dual Color (red & blue) LED Indicator

General

Power

9V DC, 1A, Ø5.5mm&Ø2.1mm Power Plug

Material

Plastic

Smart Integration

Amazon Alexa

Product Dimension

103mm x 88mm x 88mm (4.1 ×3.5 × 3.5)

Package Dimension

100mm x 100mm x 165mm (4.0 ×4.0 × 6.5)

Product Weight

206g (0.46lb)

With Package Weight

390g (0.86lb)

Protection Level

Installation Method

Desktop, Ceiling Mounting

Certification

CE, RoHS, FCC, RCM, UKCA

Temperature

Operating Temperature: -10°C ~ 45°C (14°F ~ 113°F)
Storage Temperature: -40°C ~ 70°C (-40°F ~ 158°F)

Humidity

Operating Humidity: 10% ~ 95% RH (non-condensing)
Storage Humidity: 3% ~ 95% RH (non-condensing)

Package Contents

Camera
Power Adapter (cord length: 3m)
Installation Template
Mounting Bracket
Mounting Accessories Kit
Quick Installation Guide
